Brand |
BU-LOK |
|
Equivalent To |
STAUFF, SWAGELOK, PARKER |
|
Band material |
Galvanized iron ,stainless steel 201,stainless steel 301,stainless steel 304,stainless steel 316 |
|
Band Thickness |
Galvanized iron(0.85mm) |
|
Band width |
9.7mm/11.7mm |
|
Wrench |
7mm |
|
Housing Material |
stainless steel or galvanized iron |
|
Screw style |
W1/W2/W4/W5( "-" screw) |
|
Standard |
yes |
|
Size |
As your requirement |
|
Structure |
Swivel clamp |
|
Product feature |
Volt-endurance;torque balance;large adjustment range |
|
Delivery time |
10-35days afer T/T at sight |
|
package |
Plastic bag,carton,As your requirement |
|
|
W1 |
W4 |
|
Band |
galvanized steel |
201, 301, 304 stainless steel |
|
Bridge |
galvanized steel |
201, 301, 304 stainless steel |
|
Trunnion |
galvanized steel |
201, 301, 304 stainless steel |
|
Sleeving |
galvanized steel |
201, 301, 304 stainless steel |
|
Bolt |
galvanized steel |
201, 301, 304 stainless steel |
|
Size mm |
Band width |
Thickness |
Thread |
Screw Length |
Break Torque (Nm) |
|
30-40 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
35-45 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
40-50 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
45-55 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
50-60 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
55-65 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
60-70 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
65-75 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
70-80 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
75-85 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
80-90 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
85-95 |
20mm |
1.0mm |
M6 |
45mm |
15 |
|
60-70 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
70-80 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
80-90 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
90-100 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
100-110 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
110-120 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
120-130 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
130-140 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
140-150 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
150-160 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
160-170 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
170-180 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
180-190 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
190-200 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
200-210 |
24mm |
1.0mm |
M8 |
60mm |
25 |
|
210-220 |
24mm |
1.0mm |
M8 |
60mm |
25 |
