Group |
DIN Group |
L1 (mm) |
L2 (mm) |
L3 (mm) |
B (mm) |
S (mm) |
H (mm) |
ØD1 (mm) |
ØD2 (mm) |
|
9 S |
7 |
370 |
205 |
310 |
90 |
15 |
21 |
35 |
31 |
|
8 S |
6 |
309 |
168 |
259 |
80 |
15 |
18 |
30 |
26 |
|
7 S |
5 |
238 |
122 |
198 |
60 |
10 |
12 |
24 |
21 |
|
6 S |
4 |
187 |
90 |
155 |
45 |
10 |
8 |
20 |
16 |
|
5 S |
3 |
140 |
60 |
112 |
30 |
8 |
8 |
18 |
13 |
|
4 S |
2 |
125 |
45 |
97 |
30 |
8 |
8 |
18 |
13 |
|
3 S |
1 |
113 |
33 |
85 |
30 |
8 |
8 |
18 |
13 |
|
12 S |
10 |
750 |
534 |
690 |
180 |
30 |
38 |
50 |
31 |
|
11 S |
9 |
590 |
395 |
530 |
160 |
30 |
38 |
50 |
31 |
|
10 S |
8 |
440 |
265 |
380 |
120 |
25 |
21 |
45 |
31 |
|
Brand |
BU-LOK |
|
Equivalent To |
STAUFF, SWAGELOK, PARKER |
|
Standard |
DIN 3015 |
|
Description |
Pipe Clamps Heavy Series DIN 3015, Elongated Weld Plate for Single Clamps SPAL/DUEB |
|
Material and surface finishing |
W-Code |
|
carbon steel St37, phosphated |
W2 |
|
carbon steel St37, untreated |
W1 |
|
carbon steel St37, zinc/nickel coated |
W3 |
|
stainless steel A2 - 1.4301/1.4305 (AISI 304) |
W4 |
|
stainless steel A4 - 1.4401/1.4571 (AISI 316/316Ti) |
W5 |
|
Type of Thread |
G |
|
UNC thread |
3/8-16 UNC |
|
Metric thread |
M 10 |
